Description
MicPro take a look at the AKG C568EB Shotgun Mic, this New Shotgun Shotgun Microphones by AKG. Available for delivery in the UK. Read More for details, images and how to order.
High directivity and wide frequency response in a relatively short shotgun make this microphone a perfect tool for theater, sound reinforcement, and film/TV applications.
Due to its compact and lightweight design, the C 568 B is ideal for camera mount applications.
Below 500 Hz it functions as a hypercardioid microphone; above 500 Hz the acoustic interference tube introduces increasing directivity.
A switchable 12 dB/octave 120 Hz bass cut filter effectively suppresses rumble and wind noise. The rugged, all-metal body contains the built-in preamp. Phantom powering (9-52 V) required; foam windscreen and stand adapter included.
Specifications
| Polar pattern | hypercardioid/directional |
| Frequency range | 20 to 20,000 Hz |
| Sensitivity | 11 mV/Pa (-39 dBV) |
| Max. SPL | 128 dB |
| Equivalent noise level (CCIR 468-3) | 29 dB |
| Equivalent noise level | 18 dB-A |
| Signal/noise ratio | 76 dB |
| Bass filter | 12 dB/octave at 120 Hz |
| Impedance | 600 ohms |
| Recommended load impedance | >2000 ohms |
| Supply voltage | 9 to 52 V phantom power to DIN 45596 |
| Powering | <2 mA |
| Connector | 3-pin XLR |
| Finish | dark gray |
