The Micpro team take a look at the Microtech Gefell M930 Large Diaphragm FET Condenser Microphone in Dark Bronze by , available in the Uk from a UK supplier & UK Warranty.

The M-930 studio condenser microphone combines modern large diaphragm capsule technology with advanced semiconductor circuit topology. Engineered for professional and semi professional users, it delivers exceptional performance for a variety of applications. Designed for broadcast and sound studios, the M-930 is also an excellent choice for project studios. With a cardioid polar pattern and a wide frequency range from 20 Hz to 20,000 Hz, it captures vocals, dialogue, and musical instruments with remarkable clarity.

Its electronic impedance converter ensures an ultra low noise floor while maximising output capability. This results in a clean, distortion free sound over a vast dynamic range. The microphone is highly resistant to radio frequency interference (RFI), making it a reliable choice for demanding recording environments. Supplied with the MH 93.1 microphone holder in a stylish wooden case, the M-930 is an outstanding choice for studio professionals.

Key Features:

• Superior Sound Quality:
• The M-930 delivers crystal clear audio with an extremely low noise floor, making it perfect for vocals, dialogue, and instrument recording.
• Advanced Circuit Design:
• The refined impedance converter minimises distortion and enhances output levels, providing a clean and detailed sound.
• Versatile Studio Applications:
• Ideal for broadcast, professional recording, and project studios, excelling in both voice and instrument capture.

Professional Studio Performance:

The M-930 is tailored to meet the rigorous demands of professional studio environments. Its high sensitivity and extended frequency response ensure that every nuance of a performance is accurately captured. Whether used for vocal recording, voice over work, or musical instrumentation, this microphone consistently delivers exceptional results.

Low Noise and High Output:

Thanks to its refined circuit topology, the M-930 offers an impressively low noise level of just 7dBA. This makes it one of the quietest microphones available, reducing unwanted background noise and enhancing clarity. With a dynamic range of 135dB, it excels in capturing both subtle and powerful sounds.

Durable and Reliable Construction:

Built with precision engineering, the M-930 features a robust design that ensures long term reliability. Its compact and lightweight construction makes it easy to position in various recording setups, while its high resistance to radio frequency interference guarantees seamless operation in professional studios.

Specifications:

• Polar pattern: Cardioid
• Acoustic operating principle: Pressure gradient transducer
• Frequency range: 20Hz to 20,000Hz
• Sensitivity at 1 kHz: 21mV/Pa
• Output impedance: 100Ohm
• Noise level (CCIR 468 4): 13dB
• Noise level (DIN EN 60268 4): 7dB A
• Signal to noise ratio (CCIR weighted): 81dB
• Signal to noise ratio (A weighted): 87dB
• SPL for THD 0.5%: 142dB
• Max. output level (RL = 1 kOhm): 17dBu
• Max. output level (RL = 10 kOhm): 18dBu
• Dynamic range: 135dB
• Current consumption: 3.6mA
• Output connector: XLR3M
• Weight: 210g
• Length: 118mm
• Diameter: 45mm
