Description
The LD Systems U308 HHD Wireless Microphone System with Dynamic Handheld Microphone is New Delivered to all areas of the UK using our roadie delivery service.
Here's What LD Systems U308 HHD Wireless Microphone System
Developed in Germany, the UHF diversity wireless systems from the U300® series deliver excellent audio performance. They achieve a range of 100 metres in ideal conditions and are available in five frequency bands: 584–608 MHz, 655–679 MHz, 823–832 MHz + 863–865 MHz, 470–490 MHz or 514–542 MHz. Up to six U300® systems can be used simultaneously in each frequency band. Convenient one-touch synchronisation via infrared ensures fast, problem-free wireless connection between the transmitter and receiver, while a squelch with pilot tone ensures disruption-free operation.
U300® transmitters have a 10 mW output and an operating time of 10 hours on two AA batteries. The handheld microphone’s frequency response ranges from 55 Hz to 16 KHz. With a lower cut-off frequency of 25 Hz, the bodypack is also suitable for transmitting 5-string bass guitars with a deep H string. The bodypack’s input level can be adjusted to both active and passive guitars and basses over three levels. The power switch features a handy standby mode for temporary muting. The U300® receiver is fitted with a bright LCD channel display, an LED chain for displaying audio signal strength and both a balanced XLR and an unbalanced 6.35 mm audio output. The audio output can also be switched to instrument level for directly connecting to guitar and bass amplifiers.
U300®-series wireless systems feature a fresh, modern design and are available as vocal sets with receiver and dynamic handheld microphone with cardioid characteristic, bodypack and headset or bodypack and lavalier microphone. The microphone characteristic can be changed using U500®-series replaceable heads. U300® instrument sets are available with bodypack and clip-on microphone for wind instruments or a double-shielded low-capacitance cable for guitars and basses.
- Diversity UHF wireless system with FM technology
- 12 selectable channels
- 100 m transmission range in ideal conditions
- Simultaneous operation of up to 6 systems
- ASC infrared transmitter and receiver syncing
- Pilot tone squelch
- 10 h transmitter operation on two AA batteries
- Metal housing
- Optional rackmount kit available as accessory
- U500® replacement mic heads fit the U300® handheld
Specifications
LDU308R – LD Systems U308 HHD Receiver
- Product type: Wireless Microphone System Accessories
- Type: Receivers
- Modulation: Type FM
- Antenna inputs: 2 x fixed
- Frequency response: 25 – 16,000 Hz
- Noise reduction: Squelch
- Transmission optimization: Pilot tone
- Total Harmonic Distortion (THD): < 0.3 %
- Audio output, balanced: XLR
- Audio output, unbalanced: 6.3 mm jack, switchable unbalanced output level
- Max. output level: +10 dBu (Bal), +7 dBV (Unbal, Line), +2,5 dBV (Unbal, Instr) dBu
- Controls: volume
- Indicators: LC display
- Operating voltage: 12 V DC – 18 V DC (500 mA), external power supply
- Width: 211 mm
- Height: 43 mm
- Depth: 120 mm
- Accessories (included): Power supply
- Weight 0,7 kg
LDU308MD – LD Systems U308 HHD Dynamic handheld microphone
- Type: Microphones
- Transmission frequency range: 863 – 865 MHz
- Channels: 12
- Groups: 1
- Microphone type: Dynamic
- Directivity: Cardioid
- Frequency response: 55 – 16000 Hz
- Signal-to-noise ratio: 104 dB
- Rated HF output power: 10 mW
- Operating time: >10 h
- Length: 257 mm
- Diameter: 50 mm
- Controls: Power On/Off
- Other features: Pilot tone
- Indicators: Power LED (Power ON: green)
- Operating voltage: 2 x AA battery
- Weight: 0,235 k
