Description
The DPA 2012 Compact Cardioid Microphone is New Delivered to all areas of the UK using our roadie delivery service.
The 2012 Compact Cardioid Microphone is a rugged, reliable, and flexible condenser microphone designed for close miking in live stage environments. Ideal for single instrument pickup, this mic delivers natural, detailed sound reproduction with remarkable consistency. Its cardioid polar pattern offers uniform directionality and excellent off-axis response, making it easier to manage bleed from nearby instruments. Built to endure the rigours of live performance, the 2012 features a reinforced brass body with a protective black chrome finish, ensuring long-term durability and corrosion resistance. With outstanding transient response and the ability to handle extremely high sound pressure levels, the 2012 is perfect for capturing the subtle nuances of high-frequency instruments or the sheer power of loud sources like drums and brass. From delicate acoustics to punchy electric tones, this mic provides uncompromised performance and versatility on stage, giving engineers and performers alike a dependable, professional-grade solution for any live audio scenario.
Key Features:
- Durable reinforced construction:
Crafted with a robust brass body and finished with protective black chrome, this mic is designed to resist corrosion and withstand harsh live stage conditions. - Outstanding transient response:
The condenser design captures fast, high-frequency transients with precision and clarity, outperforming dynamic mics in detail and accuracy. - Exceptional SPL handling:
With a peak SPL capacity of 156 dB, it is well suited for high-output instruments including drums, horns and electric guitars without distortion.
Precision and versatility on stage:
A professional Specialist:
The 2012 is a generalist mic with specialist capabilities, making it suitable for a broad range of instruments. Its exceptional sound clarity and frequency response give it a distinct advantage when miking high-frequency sources such as cymbals, strings and acoustic guitars. At the same time, it handles very loud instruments with ease, offering versatility in challenging live settings. The cardioid pickup pattern further enhances its adaptability, providing effective isolation of the sound source while naturally attenuating off-axis sounds.
Reliable construction for demanding environments:
On stage, microphones face intense physical demands. The 2012 has been developed specifically to meet these challenges, built from brass for structural integrity and treated with a black chrome finish for additional protection and a sleek, professional look. It is highly resistant to wear, corrosion and mechanical fatigue, making it a trusted companion for touring musicians, rental companies and sound engineers who require consistent performance in every venue.
Natural sound with reduced bleed:
Featuring a cardioid capsule with an impressively flat off-axis response, the 2012 allows for a clear and natural pickup of the primary sound source while reducing unwanted background noise. This makes it easier for sound engineers to manage bleed from adjacent instruments and prevents unnatural coloration in the mix. The result is a more controlled and faithful representation of each instrument, ideal for achieving a clean, coherent live sound.
Specifications:
- Directional pattern: Cardioid
- Principle of operation: Pressure gradient
- Cartridge type: Pre polarised condenser
- Frequency response: 20 Hz to 20 kHz
- Effective frequency range, ±2 dB, at 30 cm (11.8 in): 40 Hz to 20 kHz
- Sensitivity, nominal, ±2 dB at 1 kHz: 8 mV/Pa
- Equivalent noise level, A-weighted: Typ. 20 dB(A) re 20 µPa (max. 22 dB(A))
- Distortion, THD < 1%: 148 dB SPL, 151 dB SPL peak
- Dynamic range: Typ. 131 dB
- Max. SPL, THD 10%: 156 dB SPL peak
- Rated output impedance: 60 Ω
- Minimum load impedance: 2 kΩ
- Cable drive capability: 100 m (328 ft)
- Output balance principle: Impedance balancing with Active Drive
- Common mode rejection ratio (CMRR): > 60 dB
- Power supply (for full performance): P48 (Phantom Power)
- Current consumption: 0.7 mA
- Connector: XLR 3M, Pin 1: shield, Pin 2: signal + phase, Pin 3: – phase
- Weight: 83 g (2.9 oz)
- Microphone diameter: 19 mm (0.75 in)
- Capsule diameter: 17 mm (0.67 in)
- Microphone length: 94 mm (3.7 in)
- Maximum output voltage, RMS: 8.7 V (21 dBu)
- Polarity: +V at pin 2 for positive sound pressure
- Temperature range: -40°C to 45°C (-40°F to 113°F)
- Relative humidity (RH): Up to 90%
- Colours: Black
